DC-Pro

This thoroughly robust display controller with resistive touch and niche-free clean front can not only be installed without tools, but also offers you important security software features. Remanent hardware memory independent of the real-time clock battery, integrated temperature sensor monitoring, isolated interfaces and much more.

Also available as a dual-core device with up to 1 GB RAM, 2 GB flash, 100 kB retain.

Features:

• Available in 4", 7", 10" and 15"

• Application update via USB

• Permitted for use in residential areas

• Application protection via tamper-proof hardware identification

• Optional downgrading of the PLC cycle time down to 500μs

• Three-wire measurement to compensate for line resistance

• OpenVPN

• Universally usable VNC + HTML5 web browser

• Configurable inputs for counters and encoders

• Control buttons for resetting / stopping / starting the PLC application

• Integrated switchable termination resistors for the interfaces

• Two-stage external HW watchdog

• PT100/PT1000-compatible analog inputs

• Separate power supply for the digital outputs in groups

• Serial 9-bit multi-drop mode

• Operating hours counter
